Micrographs of a Spot of Electronics Solder

Caption

Micrographs of a spot of electronics solder demonstrate how the lithium FIB microscope (left) clearly distinguishes between the lead and tin components. An SEM image (right) captures mainly topological differences. Images show a region approximately 28 micrometers across.

Credit

Twedt/CNST

Usage Restrictions

None
