EQUIPS Workflow (IMAGE) DOE/Sandia National Laboratories Caption A traditional image-based simulation workflow converts 3D images into image segmentations using manual or convolutional neural network-based algorithms, then performs a simulation on the reconstructed segmented image. With EQUIPS, developed by Sandia National Laboratories researchers, segmentation uncertainty is calculated by creating many image segmentation samples and combining them into a probability map for simulations. Credit Courtesy of Sandia National Laboratories Usage Restrictions Credit Sandia National Laboratories License Original content Disclaimer: AAAS and EurekAlert! are not responsible for the accuracy of news releases posted to EurekAlert! by contributing institutions or for the use of any information through the EurekAlert system.
