Integrated IGT-Based Digital Logic Gates (2 of 2)

Caption

IGT-based NAND and NOR gates conform to the surface of orchid petals (left). Scale bar, 1cm. Optical micrographs of NOR (upper right) and NAND (lower right) logic gates. Input (I1, I2) and output (O) configuration is indicated. Scale bar, 100 μm.

Credit

Jennifer Gelinas/Columbia University Irving Medical Center

Usage Restrictions

Please credit as: Jennifer Gelinas/Columbia University Irving Medical Center
