Figure 2. (IMAGE)

The University of Osaka

Figure 2.

Caption

Illustration of the experiment: A blue laser diode (LD), controlled by a waveform generator (WG), is focused in the middle of the shuttle while a red laser spot partially covers its tip. Reflected red light is collected by a photodiode (PD) and the resulting electrical signal is monitored by an oscilloscope (Osc) and the frequency response of the device under study. Cutoff frequency, ~2 kHz. The device is thermalized at 50°C during excitation with the blue laser. We acquired data points manually, and observed no appreciable drift over time, indicating reproducibility over thousands of cycles.

Credit

Osaka University

Usage Restrictions

None

License

Licensed content
