Fig. 3 (IMAGE)

The University of Osaka

Fig. 3

Caption

Results of multi-imaging of mouse brain tissue. Cross-sectional profiles of the vertical white line in the figure are shown below each image. (a) Topography showing the roughness of the sample surface. (b) Amplitude image showing the change in vibration amplitude of the probe, which is suppressed in uneven tissue. (c) Phase image showing the change in vibration phase of the probe. The oscillation phase of the probe differs between the brain tissue and glass substrate. Scale bar, 1 mm.

Credit

Reproduced with permission. Copyright (2021) American Chemical Society. https://pubs.acs.org/doi/abs/10.1021/acs.analchem.0c04144
