Thinnest Optical Waveguide - 1

Caption

Illustration of a monolayer of tungsten disulfide crystal suspended in air and patterned with a square array of nanoholes. Upon laser excitation, the monolayer crystal emits photoluminescence. A portion of this light couples into the monolayer crystal and is guided along the material. At the nanohole array, periodic modulation in the refractive index causes a small portion of the light to decay out of the plane of the material, allowing the light to be observed as guided mode resonance.

Credit

Cubukcu lab

Usage Restrictions

Please credit: Cubukcu lab
