Figure 2. Structural and mechanical characterization of the nanomembrane (IMAGE)

Institute for Basic Science

Figure 2. Structural and mechanical characterization of the nanomembrane

Caption

(A-D) Scanning electron microscope image of the assembled NWs fixed in the ultrathin elastomer layer. (E-M) The great elasticity of a free-standing nanomembrane for an original state and stretched states under 250% strain and 500% strain. The applied strain is dissipated mostly by the elastomer layer, in particular by wedge regions.

Credit

Institute for Basic Science

Usage Restrictions

Attribution Required

License

Original content
