Coin Cell Battery Cross Section (IMAGE)

University of Washington

Coin Cell Battery Cross Section

Caption

Slice from x-ray computed tomography image of a supercapacitor coin cell assembled with the electrode materials. The thin layers -- just below the coin cell lid -- are layers of electrode materials and a separator.

Credit

William Kuykendall
