Optical Microscope Image of One of the Devices Used in the Experiments

Caption

The two parallel vertical lines are platinum strips which are 100 µm long, 300 nm wide and 10 nm thick. The wider connections are titanium/gold leads, used to send an electrical current I through the platinum injector and measure the voltage V over the detector (indicated schematically).

Credit

Cornelissen et al.
