Schematic of Piezo-Phototronic Device (IMAGE)

Georgia Institute of Technology

Schematic of Piezo-Phototronic Device

Caption

This schematic shows a device for imaging pressure distribution by the piezo-phototronic effect. The illustration shows a nanowire-LED based pressure sensor array before (a) and after (b) applying a compressive strain. A convex character pattern, such as "ABC," molded on a sapphire substrate, is used to apply the pressure pattern on the top of the indium-tin oxide (ITO) electrode.

Credit

Courtesy of Zhong Lin Wang

Usage Restrictions

None

License

Licensed content
