Figure 2 (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

Figure 2

Caption

(a) SEM images of single and double microdisks. The excitation laser is labeled by the green arrow. (b) The red shift of cavity modes with increasing excitation power. (c) The wavelengths, linewidths and splitting between two peaks extracted from Lorentz multi-peak fitting. (d) Statistics of linewidth differences between split modes. The resolution of the spectrometer is 0.1 nm. (e) Statistics of the splitting. The splitting of 1000 μ?V corresponds to 0.80 nm at the wavelength of 1000 nm. (f) Distribution of the splitting and half Gaussian fitting

Credit

Jingnan Yang, Chenjiang Qian, Xin Xie, Kai Peng, Shiyao Wu, Feilong Song, Sibai Sun, Jianchen Dang, by Yang Yu, Shushu Shi, Jiongji He, Matthew J. Steer, Iain G. Thayne, Bei-Bei Li, Fang Bo, Yun-Feng Xiao, Zhanchun Zuo, Kuijuan Jin, Changzhi Gu, and Xiulai Xu
