Figure 2 Band properties of the finite circuit containing 2.5×2.5×2.5 unit cells (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

Figure 2 Band properties of the finite circuit containing 2.5×2.5×2.5 unit cells

Caption

(a) Eigenvalue of J(ω) of the finite circuit as the frequency varies from 0 to 8 MHz. The isolated curve crosses zero admittance at the corner mode frequency 2.77 MHz. This plot has been rotated by 90° to enable a better comparison with the sorted eigenfrequency plot in (b). (b) Sorted eigenfrequencies of the finite circuit. The isolated mode in the bandgap is the nontrivial octupole corner mode.

Credit

by Shuo Liu, Shaojie Ma, Qian Zhang, Lei Zhang, Cheng Yang, Oubo You, Wenlong Gao, Yuanjiang Xiang, Tie Jun Cui & Shuang Zhang
