Hall-Bar Device Structure (See Inset) Wire-Bonded to a 16-Pin Chip-Carrier

Caption

A Hall-bar device structure (see inset) is wire-bonded to a 16-pin chip-carrier. The chip-carrier allows for extensive electrical characterization of the device at both low temperatures and high magnetic fields.

Credit

Min Sup Choi/Columbia Engineering

Usage Restrictions

Please credit as: Min Sup Choi/Columbia Engineering
