Schematic of Microreactor and Reaction Space

Caption

Schematic of the microreactor and reaction space, designed by Ryan Hartman, professor of chemical and biomolecular engineering at the NYU Tandon. Illustration (a) shows water cooler block, electrical connections, bottom chuck, fluidic connections, top chuck, screws, O-rings, reactor chip and peltier cells; images (b) to (d) illustrate flow of liquified zirconocene polymer catalyst in reactor space.

Credit

Ryan Hartman, Ph.D.
