Introducing Thermal Lithography for Biochips (IMAGE)
Caption
This is an image of a one-atom-deep layer of molybdenum disulfide with electrodes patterned by hot nano-tip in a new process called thermal scanning probe lithography. Researchers at NYU Tandon School of Engineering invented the process to produce high-quality semiconductors at a cost significantly lower than current electron beam lithography.
