Figure 1. Agile 3D Sketching Workflow with Air Scaffolding (IMAGE)

The Korea Advanced Institute of Science and Technology (KAIST)

Figure 1. Agile 3D Sketching Workflow with Air Scaffolding

Caption

Figure 1. In the agile 3D sketching workflow with air scaffolding, the user (a) makes unconstrained hand movements in the air to quickly generate rough shapes to be used as scaffolds, (b) uses the scaffolds as references and draws finer details with them, (c) produces a high-fidelity 3D concept sketch of a steering wheel in an iterative and progressive manner.

Credit

KAIST

Usage Restrictions

None
