Voltage Regulation

Caption

The multi-core voltage regulator responds almost instantaneously to changes in power demand from each core of the processor. As a result, the power supply matches the demand more closely, conserving energy.

Credit

Image courtesy of Wonyoung Kim, Harvard School of Engineering and Applied Sciences

Usage Restrictions

None
