Figure 2. System schematic of MFOR-PAMER.

Caption

A 532-nm pulsed laser beam is spatially filtered and expanded before focusing through the microlens array. The focusing plane of the microlens array is then imaged onto the imaging face of the ER prism to illuminate the imaging object. A single-element ultrasonic transducer is attached to a corner of the ER to detect encoded PA signals.

Credit

by Yang Li, Terence T. W. Wong, Junhui Shi, Hsun-Chia Hsu, and Lihong V. Wang
