The Proposed Variable Thrust Direction Mechanism

Caption

The proposed variable thrust direction mechanism is shown in Fig.1, a conventional propeller engine is mounted on a two dimensional rotate disk, which is driven by two servo actuators. By combining the linear motions of the actuator, both the azimuth and the altitude angle of the disk with respect to the fuselage can be controlled, and thus changing the thrust direction of the propeller.

Credit

©Science China Press
