Microscopy Image of Carbon Nanotubes

Caption

This microscopy image shows the damaged outer walls of double- and triple-walled carbon nanotubes (CNT) after being treated in a chemical solution. This technique could help make carbon nanotubes an attractive, low-cost alternative to platinum catalysts in fuel cells.

Credit

Hongie Dai Lab/Stanford University
