Faster thin film devices for energy storage and electronics (IMAGE)

Max-Planck-Institut für Mikrostrukturphysik

Faster thin film devices for energy storage and electronics

Caption

Hyeon Han and Stuart Parkin in front of the pulsed laser deposition system (Pascal Co., Ltd., Ibaraki, Japan) at the Max Planck Institute of Microstructure Physics that was used to create the single crystalline T-Nb2O5 films used in the study.

Credit

MPI of Microstructure Physics, Eric Geißler
