Revolutionizing root phenotyping: automated total root length estimation from in situ images without segmentation

Peer-Reviewed Publication

Nanjing Agricultural University The Academy of Science

Figure 3.


Comparison of root images taken using (A) a conventional manual MR system or (B) an automated MR system.

view more

Credit: Plant Phenomics

Climate change stresses severely limit crop yields, with root traits playing a vital role in stress tolerance, thus highlighting the importance of root phenotyping for crop improvement. Recent advances in image-based root phenotyping, particularly through the minirhizotron (MR) technique, offer insights into root dynamics under stress. However, the manual and subjective nature of MR image analysis poses significant challenges. This highlights the need for automated imaging systems and tools to streamline and objectify the process, enhancing the efficiency and objectivity of root phenotyping.

In January 2024, Plant Phenomics published a research article entitled by “Automatic Root Length Estimation from Images Acquired In Situ without Segmentation”. This study advances the field of root phenotyping by adapting convolutional neural network-based models for estimating total root length (TRL) from MR images without the need for segmentation.

Utilizing manual annotations from Rootfly software, researchers explored a regression-based model and a detection-based model that identifies annotated root points, with the latter offering a visual inspection capability of MR images. The models were rigorously tested across 4,015 images from diverse crop species under varied abiotic stresses, demonstrating high accuracy (values between 0.929 and 0.986) in TRL estimation compared to manual measurements. This accuracy underscores the potential of our approach to significantly enhance root phenotyping's efficiency and reliability.

The study's results indicate that the detection-based model generally outperforms the regression model, particularly in challenging datasets, by incorporating additional root coordinate information. This finding is critical for high-quality image datasets, where automated TRL estimation remains robust. Moreover, researchers conducted a sensitivity analysis to highlight the impact of image quality and dataset size on model performance, revealing the significant influence of image quality. The models' ability to differentiate between images with and without roots, with a minimal error margin, further illustrates their practical utility in precision agriculture by enabling real-time monitoring of root growth.

The analysis was then extended to evaluate root length density (RLD) calculations, demonstrating the models' effectiveness in capturing root distribution patterns in soil, which is vital for understanding water and nutrient extraction. The models' capability to track root dynamics over time—including the identification of root disappearance—highlights their potential to inform timely agricultural decisions regarding water and nutrient management.

In conclusion, this research presents a groundbreaking approach to root phenotyping, offering robust, automated tools for TRL estimation from MR images, thereby facilitating the rapid and accurate assessment of root growth patterns. This advancement holds significant promise for enhancing precision agriculture practices, enabling growers to make informed decisions based on detailed root growth information.




Faina  Khoroshevsky1*†, Kaining  Zhou2,8†, Sharon  Chemweno3,8,  Yael  Edan1, Aharon  Bar-Hillel1, Ofer  Hadar4, Boris Rewald5,6,  Pavel  Baykalov5,7, Jhonathan E.  Ephrath8, and Naftali  Lazarovitch8


1Department of Industrial Engineering and Management, Ben-Gurion University of the Negev, Beer Sheva, Israel.

2The Jacob Blaustein Center for Scientific Cooperation, The Jacob Blaustein Institutes for Desert Research, Ben-Gurion University of the Negev, Sede Boqer, Israel.

3The Albert Katz International School for  Desert  Studies,  The  Jacob  Blaustein  Institutes  for  Desert  Research,  Ben-Gurion  University  of  the  Negev,  Sede  Boqer,  Israel.

4Department  of  Communication  Systems  Engineering,  School  of  Electrical  and  Computer  Engineering,  Ben-Gurion  University  of  the  Negev,  Beer  Sheva,  Israel.

5Institute  of  Forest  Ecology,  Department  of  Forest  and  Soil  Sciences,  University  of  Natural  Resources  and  Life  Sciences,  Vienna (BOKU), Vienna, Austria.

6Faculty  of  Forestry  and  Wood  Technology,  Mendel  University  in  Brno,  Brno, Czech Republic.

7Vienna Scientific Instruments GmbH, Alland, Austria.

8French Associates Institute for Agriculture and Biotechnology of Drylands, The Jacob Blaustein Institutes for Desert Research, Ben-Gurion University of the Negev, Sede Boqer, Israel.
