News Release

Researchers develop high-energy-density aqueous battery based on halogen multi-electron transfer

Peer-Reviewed Publication

Dalian Institute of Chemical Physics, Chinese Academy Sciences

Researchers develop high-energy-density aqueous battery based on halogen multi-electron transfer

image:

Multi-electron transfer cathode based on bromo and iodine

view more

Credit: DICP

Traditional non-aqueous lithium-ion batteries have a high energy density, but their safety is compromised due to the flammable organic electrolytes they utilize.

Aqueous batteries use water as the solvent for electrolytes, significantly enhancing the safety of the batteries. However, due to the limited solubility of the electrolyte and low battery voltage, aqueous batteries typically have a lower energy density. This means that the amount of electricity stored per unit volume of aqueous battery is relatively low.

In a new study published in Nature Energy, a research group led by Prof. LI Xianfeng from the Dalian Institute of Chemical Physics (DICP) of the Chinese Academy of Sciences (CAS), in collaboration with Prof. FU Qiang's group also from DICP, developed a multi-electron transfer cathode based on bromine and iodine, realizing a specific capacity of more than 840 Ah/L, and achieving an energy density of up to 1200 Wh/L based on catholyte in full battery testing.

To improve the energy density of aqueous batteries, researchers used a mixed halogen solution of iodide ions (I-) and bromide ions (Br-) as the electrolyte. They developed a multi-electron transfer reaction, transferring I- to iodine element (I2) and then to iodate (IO3-). During the charging process, I- were oxidized to IO3- on the positive side, and the generated H+ were conducted to the negative side in the form of supporting electrolyte. During the discharge process, H+ were conducted from the positive side, and IO3- were reduced to I-.

The developed multi-electron transfer cathode had a specific capacity of 840 Ah/L. Combining the cathode with metallic Cd to form a full battery, researchers achieved an energy density up to 1200 Wh/L based on the developed catholyte.

Besides, researchers confirmed that Br- added to the electrolyte could generate polar iodine bromide (IBr) during the charging process, which facilitated the reaction with H2O to form IO3-. During the discharge, IO3- could oxidize Br- to Br2 and participated in the electrochemical reaction to realize reversible and rapid discharge of IO3-. Therefore, the bromide intermediate formed during the charge and discharge process optimized the reaction process, effectively improving the kinetic and reversibility of the electrochemical reaction.

Prof. FU's group proved the multi-electron transfer process through in-situ optical microscopy, Raman spectroscopy and so on.

"This study provides a new idea for the design of high-energy-density aqueous batteries, and may expand the aqueous batteries application in power batteries field," said Prof. LI.
