Macroscopic superlubricity achieved by the synergic effect of silver nanoparticles and hexagonal boron nitride nanosheets

Superlubricity is a lubrication state with a coefficient of friction of less than 0.01, enabling efficient and stable mechanical operation under near-zero wear conditions. Although 2D nanomaterials have been tried to be used as additives in liquid lubricants to obtain the superlubricity, they tend to undergo a long break-in period accompanied by intense wear before reaching superlubricity, resulting in low load-bearing pressure. Therefore, the challenge of low load bearing pressure of 2D nanomaterials needs to be addressed in order to achieve long service life of the friction pair.

A team of lubrication scientists led by Jinjin Li from Tsinghua University in Beijing, China recently based on the synergistic effect of silver (Ag) nanoparticles and hexagonal boron nitride (hBN) nanosheets, a superlubricity state with high load-bearing pressure was achieved. The Ag nanoparticles were introduced on the surface of hBN sheets using dopamine as a linker. Further, the silver-modified hBN nanosheets (hBN-Ag) were used as additives to the aqueous ethylene glycol solution. The results showed that a superlubricity condition with a minimum coefficient of friction about 0.004 was achieved without a break-in period at a maximum contact pressure of 1.20 GPa. The achievement of superlubricity was attributed to the synergistic effect of Ag nanoparticles and hBN nanosheets, in which Ag nanoparticles were attached to hBN nanosheets to enhance the load-bearing capacity of hBN nanosheets. The Ag-modified hBN nanosheets produce extremely low friction and wear, contributing to the development of lubricants with high load bearing pressure and low wear rate.

The team published their paper in Nano Research on March 17, 2025.

In this work, Ag nanoparticles were deposited on the hBN surface through the reduction reaction of silver ions, revealing the synergistic superlubricity mechanism of hBN nanosheets and silver nanoparticles. Ag nanoparticles were tightly attached to hBN nanosheets and will not be detached from the surface during friction. The Ag-attached hBN nanosheets were more likely to be adsorbed and deposited on the friction interface, generating the tribofilm containing hBN-Ag nanosheets. The tribofilm reduced the direct contact of the friction pair and provided lower shear strength.

This work provides a new strategy for the achievement of superlubricity with hBN nanosheets under high load-bearing pressure by the modification of nanoparticles, contributes to the development of high-performance lubrication systems and opens up a new avenue for the application of 2D nanomaterials.

Other contributors include Yongfeng Yang, Rui Zhang, Shaowen Dong, and Xiaoyang Ma from the State Key Laboratory of Tribology in Advanced Equipment, Tsinghua University, China.

This work was supported by the National Key R&D Program of China (2020YFA0711003), National Natural Science Foundation of China (52175174, U2268212).

About the Authors

Dr. Jinjin Li is a full associate professor in the State Key Laboratory of Tribology in Advanced Equipment, Tsinghua University, China. His research interests focus on the mechanical surface lubrication theory, nano-additives and superlubricity technology. He has published over 100 research papers in prestigious international journals and received more than 20 Chinese national invention patents in recent years. For more information, please pay attention to his research homepage https://www.me.tsinghua.edu.cn/info/1095/2367.htm
