Updates to Slicer 2 software include better visuals and automation
image: Polymer 3D printing, or additive manufacturing, is achieved by extruding heated plastic through a nozzle. The material extruded in this image is glass fiber reinforced PETG, building a tooling jig for object alignment. The Slicer 2 software developed by ORNL provides directions to the printer on how to make specific shapes.
Credit: Amy Burgess/ ORNL, US Dept. of Energy
The U.S. Department of Energy’s (DOE) Oak Ridge National Laboratory has released a new version of its advanced slicing software, ORNL Slicer 2, which accelerates and simplifies the creation of large 3D printed parts.
Slicer 2 works for all materials used in the additive manufacturing processes of directed energy deposition and material extrusion.
Current slicing software translates a computer-aided design (CAD) model into two-dimensional layers, calculating machine paths and speeds needed to fabricate a part. Slicer 2 improves on this by integrating multiple types of 3D printers and sensors while supporting real-time process optimization with advanced manufacturing systems.
“The latest release of Slicer 2 includes many significant updates, improvements, and bug fixes,” said Alex Roschli, a researcher in ORNL’s System Automation and Monitoring group. “One major change is a new system that helps automate the creation of files that can be easily distributed to our users.”
The updates include improved visualizations for a more accurate rendering of cross-sections for tool-pathing. By better understanding how a tool cuts through the material at different depths, the software enables greater precision in making desired shapes.
The team added the ability to simulate, before beginning a print, the effects of multiple bead widths (the width of the extruded materials). While bead width is largely determined by the diameter of a 3D printer’s nozzle, the slicing software can adjust the width during printing to create more complex forms. Based on the dynamic width created by Slicer 2, a machine implements real-time controls based on calibration values and sensor readings.
The latest update of Slicer 2 will help manufacturers stay competitive by reducing costs, improving part quality, and enabling faster production cycles for complex components — capabilities that are essential for scaling up additive manufacturing while maintaining consistency and reducing waste.
ORNL Slicer 2 is used by aerospace, automotive, and defense organizations for tooling, delivering reliable end-use components and prototyping next-generation designs.
Roschli collaborated on this update with Liam White, Cameron Adkins, Ashley Gannon and Michael Borish of ORNL’s Research Application Development group.
