Researchers in China have engineered bendable batteries that can run on body-inspired liquids such as normal IV saline solution and cell-culture medium. In their work, published August 10 in the journal Chem, the authors designed alternatives to lithium-ion batteries by focusing on the mechanical-stress demands of wearable electronics such as smartwatches and the safety requirements of implantable electronics.
"Current batteries like the lithium-ion ones used in medical implants generally come in rigid shapes," says co-senior author Yonggang Wang, a chemistry professor at Fudan University and the Collaborative Innovation Center of Chemistry for Energy Materials. "Additionally, most of the reported flexible batteries are based on flammable organic or corrosive electrolytes, which suffer from safety hazards and poor biocompatibility for wearable devices, let alone implantable ones."
Safety measures for wearable and implantable batteries have generally involved structural reinforcement to prevent hazardous chemicals from leaking out. Instead, the researchers, led by Wang and macromolecular science professor Huisheng Peng, swapped out those toxic and flammable liquids for cheap and environmentally conscious sodium-ion solutions. Among those solutions were two biocompatible ones suitable for implantable devices, given that they pose no harm to the surface or interior of the body. Although electrolyte leakage is still undesired, its danger is minimized by the use of either the normal saline solution pumped into the body in most IV treatments or a cell-culture medium that contains amino acids, sugars, and vitamins in addition to sodium ions and thus mimics the fluid that surrounds human cells.
Freed from leakage concerns, which can require so much protective material that batteries become bulky and unbendable, the researchers designed two types of flexible batteries--a 2D "belt"-shaped battery for which they adhered thin electrode films to a net of steel strands and a 1D fiber-shaped battery for which they embedded nanoparticles of electrode material around a carbon nanotube backbone. Besides testing biocompatible fluids, the authors also tested ordinary sodium sulfate, a safe and fairly inert solution, as a liquid electrolyte suitable for use in external wearable devices.
With sodium sulfate solution as the electrolyte, both battery types outperformed most of the reported wearable lithium-ion batteries in terms of charge-holding capacity (an indicator of how long a battery can function without recharging) and power output for their size. That performance held up when the authors folded and bent the batteries to mimic the impact of wrapping a sensor, watch, or similar device around one's arm. Charge-holding capacity was only marginally reduced for the saline- and cell-culture-based batteries, most likely because they had slightly lower sodium-ion content than the sodium sulfate solution.
An undesired side reaction involving their fiber-shaped battery is even pointing the researchers toward possible biomedical applications. The same carbon nanotubes that make up the skeleton of the 1D battery can also accelerate the conversion of dissolved oxygen into hydroxide ions, a process that harms battery effectiveness if left uncontrolled but as a stand-alone process boasts therapeutic potential for treating cancer and bacterial infections.
"We can implant these fiber-shaped electrodes into the human body to consume essential oxygen, especially for areas that are difficult for injectable drugs to reach," says Wang. "Deoxygenation might even wipe out cancerous cells or pathogenic bacteria since they are very sensitive to changes in living environment pH. Of course, this is hypothetical right now, but we hope to investigate further with biologists and medical scientists."
This work was supported by the National Science Foundation of China and the State Key Basic Research Program of the People's Republic of China.
Chem, Guo et al.: "Multi-functional Flexible Aqueous Sodium-Ion Batteries with High Safety" http://www.cell.com/chem/fulltext/S2451-9294(17)30217-6
