Anyone who skis, wears glasses, uses a camera or drives a car is familiar with the problem: if you come into a humid environment from the cold, your eyewear, camera lens or windshield can quickly fog up. Researchers at ETH Zurich have now developed a new transparent material coating that greatly reduces this effect. Just a few nanometres thick, their durable coating is made of gold nanoparticles embedded in non-conductive titanium oxide.
"Our coating absorbs the infrared component of sunlight along with a small part of the visible sunlight and converts the light into heat," explains Christopher Walker, a doctoral student in ETH Professor Dimos Poulikakos's group and lead author of the study. This heats the surface up by 3 to 4 degrees Celsius. It is this difference in temperature that prevents fogging.
Heat is also the answer to the problem of fogging on car windows. Warm air from the in-vehicle heating system heats the front windscreen, while the rear window is fitted with a grid of electrical heating elements. But unlike these methods, the ETH researchers' new coating works passively. Since the only energy source required is the sun, their coating is especially suitable for wearable items such as glasses and goggles.
Efstratios Mitridis, another doctoral student in Poulikakos's group, explains what makes the new surface coating so special: "Normally, it's dark surfaces that absorb light and convert it into heat," he says, "but we've created a transparent surface that has the same effect."
Better than anti-fog sprays
Condensation occurs on a surface whenever there is a sudden drop in temperature or increase in humidity, forming tiny droplets of water that disperse incident light in different directions in much the same way as atmospheric fog. As an alternative to using heat to prevent fogging, susceptible surfaces can be coated with hydrophilic agents. Because they attract water, these agents ensure that the condensation forms an even thin film of liquid over the surface rather than separate droplets. Anti-fog sprays for glasses usually work on this principle.
Now, tests have shown that when exposed to sunlight, fogged surfaces coated with gold nanoparticles and titanium oxide clear four times faster than surfaces treated with a normal anti-fog agent. "Spray treatments often lose their effect after a while because the anti-fog film dries up or becomes unevenly distributed," Walker says. "A durable coating like ours lasts much longer than a spray treatment, which you have to apply virtually on a daily basis," he adds.
The ETH scientists are now planning to bring their new method to market, in collaboration with a partner from industry. "We're looking to refine our already robust coating to ensure it lasts for years, and we want to take the technology from lab scale to industry scale," Walker says. Their coating has a huge range of potential applications, including car windshields and rear-view mirrors as well as ski goggles and diving masks.
Walker C, Mitridis E, Kreiner T, Eghlidi H, Schutzius TM, Poulikakos D: Transparent Metasurfaces Counteracting Fogging by Harnessing Sunlight, Nano Letters, 28 January 2019, doi: 10.1021/acs.nanolett.8b04481 [http://dx.doi.org/10.1021/acs.nanolett.8b04481]
