“Virtual pillars” separate and sort blood-based nanoparticles

Sorting biological nanoparticles 500 times thinner than a human hair could improve a wide variety of diagnostics and treatments

Peer-Reviewed Publication

Duke University

Particle Separation

video: A single sound wave creates a series of “virtual pillars” down the middle of a fluid-filled channel, gently moving nanoparticles within to the side. The technology can separate and sort medically important nanoparticles from biofluids, which could be used to detect diseases such as cancer or Alzheimer’s disease. view more

Credit: Jinxin Zhang, Duke University

DURHAM, N.C. – Engineers at Duke University have developed a device that uses sound waves to separate and sort the tiniest particles found in blood in a matter of minutes. The technology is based on a concept called “virtual pillars” and could be a boon to both scientific research and medical applications.

Tiny biological nanoparticles called “small extracellular vesicles” (sEVs) are released from every type of cell in the body and are believed to play a large role in cell-to-cell communication and disease transmission. The new technology, dubbed Acoustic Nanoscale Separation via Wave-pillar Excitation Resonance, or ANSWER for short, not only pulls these nanoparticles from biofluids in under 10 minutes, it also sorts them into size categories believed to have distinct biological roles.

The results appeared online November 23 in the journal Science Advances.

“These nanoparticles have significant potential in medical diagnosis and treatment, but the current technologies for separating and sorting them take several hours or days, are inconsistent, produce low yield or purity, suffer from contamination and sometimes damage the nanoparticles,” said Tony Jun Huang, the William Bevan Distinguished Professor of Mechanical Engineering and Materials Science at Duke.

“We want to make extracting and sorting high-quality sEVs as simple as pushing a button and getting the desired samples faster than it takes to take a shower,” Huang said.

Recent research indicates that sEVs are comprised of several subgroups with distinct sizes (e.g., smaller than 50 nanometers, between 60 and 80 nanometers, and between 90 and 150 nanometers). Each size is believed to have different biological properties.

The recent discovery of sEV subpopulations has excited researchers because of their potential to revolutionize the field of non-invasive diagnostics, such as the early detection of cancer and Alzheimer’s disease. But the particles haven’t found their way into clinical settings yet.

Huang said this is largely due to the difficulties associated with separating and isolating these nano-sized sEV subpopulations. To meet this challenge, Huang, his doctoral student Jinxin Zhang, and collaborators at UCLA, Harvard, and Magee-Womens Research Institute, developed the ANSWER platform.

The device uses a single pair of transducers to generate a standing sound wave that envelops a narrow, enclosed channel filled with fluid. The sound wave "leaks" into the liquid center through the channel walls and interacts with the original standing sound wave. With careful design of the wall thickness, channel size and sound frequency, this interaction creates a resonance that forms "virtual pillars" along the center of the channel.

Each of these virtual pillars is essentially a half-egg-shaped region of high pressure. As particles attempt to cross over the pillars, they get pushed toward the edges of the channel. And the bigger the particles, the bigger the push. By tuning the series of virtual pillars to create nuanced forces on the traveling nanoparticles, the researchers can precisely sort them by size into a variety of groups determined by the needs of the experiments at hand.

“The ANSWER EV fractionation technology is the most advanced capability for precise EV fractionation, and it will significantly impact the horizon of EV diagnostics, prognostics and liquid biopsy,” said David Wong, director for UCLA Center for Oral/Head & Neck Oncology Research.

In the new paper, the researchers demonstrate that their ANSWER platform can successfully sort sEVs into three subgroups with 96% accuracy for nanoparticles on the larger end of the spectrum and 80% accuracy for the smallest. They also show flexibility in their system, adjusting the number of groupings and ranges of sizes with simple updates to the sound wave parameters. Each of the experiments only took 10 minutes to complete, whereas other methods such as ultra-centrifugation can take several hours or days.

“Due to its contact-free nature, ANSWER offers a biocompatible approach for the separation of biological nanoparticles.” Zhang said. “Unlike mechanical filtration methods, which have fixed separation cutoff diameters, ANSWER offers a tunable approach to nanoscale separation, and the cutoff diameter can be precisely modified by varying the input acoustic power.”

Moving forward, the researchers will continue improving the ANSWER technology so that it can be efficient in purifying other biologically relevant nanoparticles such as viruses, antibodies and proteins.

This research was supported by the National Institutes of Health (UH3TR002978, R01HD103727, U18TR003778, R01GM132603, R01GM143439 R01GM135486, R01GM144417, R44AG063643) and the National Science Foundation (CMMI-2104295, CMMI-2104526).

CITATION: “A Solution to the Biophysical Fractionation of Extracellular Vesicles: Acoustic Nanoscale Separation via Wave-pillar Excitation Resonance (ANSWER),” Jinxin Zhang, Chuyi Chen, Ryan Becker, Joseph Rufo, Shujie Yang, John Mai, Peiran Zhang, Yuyang Gu, Zeyu Wang, Zhehan Ma, Jianping Xia, Nanjing Hao, Zhenhua Tian, David T. W. Wong, Yoel Sadovsky, Luke P. Lee, and Tony Jun Huang. Science Advances, Nov. 23, 2022. DOI: 10.1126/sciadv.ade0640

# # #
