Tiny surgical robots could transform detection and treatment of cancers

A tiny robot which can travel deep into the lungs to detect and treat the first signs of cancer has been developed by researchers at the University of Leeds

Peer-Reviewed Publication

University of Leeds

Phantom lung - navigation and localisation

video: Demonstration of phantom lung - navigation and localisation using magnetic personalised tentacles view more

Credit: Courtesy of STORM Lab, University of Leeds

The ultra-soft tentacle, which measures just 2 millimetres in diameter and is controlled by magnets, can reach some of the smallest bronchial tubes and could transform the treatment of lung cancer.

It paves the way for a more accurate, tailored, and far less invasive approach to treatment and has been developed by engineers, scientists and clinicians based at the STORM Lab in Leeds.

The researchers tested the magnetic tentacle robot on the lungs of a cadaver and found that it can travel 37% deeper than the standard equipment and leads to less tissue damage.

The results of their investigations, which were funded by the European Research Council, are published today in Nature Engineering Communications

Professor Pietro Valdastri, Director of the STORM Lab and research supervisor, said: “This is a really exciting development.

“This new approach has the advantage of being specific to the anatomy, softer than the anatomy and fully-shape controllable via magnetics. These three main features have the potential to revolutionize navigation inside the body.”

Lung cancer has the highest worldwide cancer mortality rate. In early-stage non-small cell lung cancer, which accounts for around 84% of cases, surgical intervention is the standard of care. However, this is typically highly invasive and leads to the significant removal of tissue. This approach is not suitable for all patients and can have an impact on lung function.

Lung cancer screening programmes have led to better survival rates but have also highlighted the urgent need to find non-invasive ways to diagnose and treat patients early.

As well as improving navigation within the lungs during biopsies, the magnetic tentacle robot could pave the way for far less invasive treatment, allowing clinicians to target only malicious cells while allowing healthy tissue and organs to continue normal function.

The report’s co-author, Dr Giovanni Pittiglio, who carried out the research while conducting his PHD at the University of Leeds’s School of Electronic and Electrical Engineering, added: “Our goal was, and is, to bring curative aid with minimal pain for the patient.

“Remote magnetic actuation enabled us to do this using ultra-soft tentacles which can reach deeper, while shaping to the anatomy and reducing trauma.”

The team will now set about collecting all the data that will allow them to start human trials

How magnetic tentacle robots can work together

Researchers at the STORM Lab have also been investigating ways of controlling two independent magnetic robots so that they can work together in a confined area of the human anatomy, allowing one to move a camera and the other to control a laser to remove tumours.

The devices are made of silicone to minimise tissue damage and are steered by magnets mounted on robotic arms outside the patient’s body.

Using a replica of a skull, the team successfully trialled the use of two robots to carry out endonasal brain surgery, a technique which allows a surgeon to go through the nose to operate on areas at the front of the brain and the top of the spine.

The researchers needed the magnetic robots to move independently of each other so that one could move the camera, while the other could direct a laser onto a tumour.

Normally, two magnets placed closely together would attract each other, creating a challenge for the researchers. They overcame it by designing the bodies of the tentacles in a way that they can bend only in specific directions and by relocating the north and south poles in each magnetic robot tentacle.

They were then able to simulate the removal of a benign tumour on the pituitary gland at the base of the cranium, proving for the first time ever that it is possible to control two of the robots in one confined area of the body.

The findings of their research, which was jointly funded by the European Research Council and the Physical Sciences Research Council, is published today in Advanced Intelligent Systems.

The paper’s lead author, Zaneta Koszowska, a researcher in the University of Leeds School of Electronic and Electrical Engineering, said: “This is a significant contribution to the field of magnetically controlled robotics.

“Our findings show that diagnostic procedures with a camera, as well as full surgical procedures, can be performed in small anatomical spaces.”
