Figure 3 | The photoelectric performance of WS₂ lateral p-n homojunction photodetector

Caption

(a) Schematic illustration of photodetector based on lateral WS2 p-n homojunction. (b) Output characteristic curves of lateral WS2 p-n homojunction under 532 nm illumination with different light power densities. (c) The magnified output characteristic curves of (b). (d) Transient photo-response of lateral WS2 p-n homojunction under 532 nm illumination with different light power densities at bias and gate voltage of 0 V. (e) Rise and (f) fall time curve of transient photo-response under 532 nm illumination (4.96 mW cm-2) at bias of 1 V.

Credit

by Yufan Kang, Yongfeng Pei, Dong He, Hang Xu, Mingjun Ma, Jialu Yan, Changzhong Jiang, Wenqing Li, and Xiangheng Xiao

Usage Restrictions

Credit must be given to the creator.

License

CC BY
