Figure 2 | The measurement results of KPFM and electrical performance on WS₂ lateral p-n homojunction (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

Figure 2 | The measurement results of KPFM and electrical performance on WS₂ lateral p-n homojunction

Caption

(a) The contrastive KPFM mapping of the WS2 lateral p-n homojunction. The scale bar is 3 μm. (b) The surface potential difference of WS2 lateral p-n homojunction marked with the red line in (a). (c) Output characteristic curves of lateral WS2 p-n homojunction FET at different gate voltages. (d) Transfer characteristic curves of WS2 and N-WS2 (with implantation dose of 1×1014 ions cm-2) FETs at bias of 1 V

Credit

by Yufan Kang, Yongfeng Pei, Dong He, Hang Xu, Mingjun Ma, Jialu Yan, Changzhong Jiang, Wenqing Li, and Xiangheng Xiao

Usage Restrictions

Credit must be given to the creator.

License

CC BY
