Figure 2 (IMAGE)

Tohoku University

Figure 2

Caption

Elemental Mapping of Hydroxyapatite Particles Using Cryo-EELS imaging. (Left) The conventional cryo-TEM image shows the size, shape, and dispersion of the hydroxyapatite particles. (Center and right) Calcium and phosphorus--constituent elements of hydroxyapatite--are successfully detected and visualized.

Credit

©Daisuke Unabara et al.
