Figure 2. OAM mapping based on inversely-designed meta-waveguide.

Caption

Figure 2. OAM mapping based on inversely-designed meta-waveguide. Mapping gratings converting diverse waveguide-modes to OAM beams are initially constructed based on the holographic principle. Following structural discretization, the patterns are finely optimized via inverse design algorithms. The resulting meta-waveguide enables high-purity mapping between eight distinct guided waveguide modes and eight free-space vortex beams with prescribed polarizations and orbital angular momenta.

Credit

Minming Zhang et al.

Usage Restrictions

Credit must be given to the creator.

License

CC BY
