Solar Panels Thermal Image

Caption

Left: A Google Earth image of the Powell Structural Systems Laboratory with a tilted solar panel array on the north side and a flush solar panel array on the center of the roof. Right: A thermal infrared image of the ceiling of the Powell Structural Systems Laboratory, taken at 5:10 p.m. April 19, 2009. The color bar shows temperatures in degrees Kelvin. The footprint of the tilted solar panel array is visible as a cool area in the center of the image.

Credit

Jacobs School of Engineering at UC San Diego

Usage Restrictions

None

License

Licensed content
