Relationship between cooling performance and temperature of cooled surface (IMAGE)
Caption
Relationship between heat flux and temperature of a cooling surface was evaluated in cases of water (circle in red) and fluorine-based refrigerant (triangle in blue) (a) Regime for server cooling (b) Regime for Si power electronics (c) Regime for SiC power electronics for EVs and HEVs
Credit
Lotus Thermal Solution
Usage Restrictions
The image only be used with “Provided by Lotus Thermal Solution”
License
Original content
