Structure of the symmetrical dual-chamber system (left) and the main chamber (right). (IMAGE)

Nuclear Science and Techniques

Structure of the symmetrical dual-chamber system (left) and the main chamber (right).

Caption

This figure presents the innovative symmetrical dual-chamber design of INPC-TPC and the internal layout of the main chamber. Chamber 1 (for fission fragments and alpha particles) and Chamber 2 (for recoil protons) are spatially isolated, reducing the dynamic range requirement of a single chamber from 4000-fold to a manageable level. The measured target (e.g., 235U) is placed on the cathode plate of Chamber 1, while the reference target (polyethylene) is mounted in the corresponding position of Chamber 2. Neutrons induce fission in Chamber 1 and elastic scattering with hydrogen in Chamber 2, enabling cross-section ratio calculation based on recoil proton counts.

Credit

Jia-Jun Zhang

Usage Restrictions

Credit must be given to the creator. Only noncommercial uses of the work are permitted.

License

CC BY-NC
