Structure of the partitioned target (a) and the electronics system (b). (IMAGE)

Nuclear Science and Techniques

Structure of the partitioned target (a) and the electronics system (b).

Caption

Part (a) shows the partitioned target for simultaneous measurement of 235U and 238U: an 80 µm-thick aluminum substrate (32 mm diameter) divided into four quarter-circle regions (15 mm radius), with 235U and 238U deposited diagonally (99.9% purity, 8% thickness uniformity) and polyethylene on the back for recoil proton detection. Part (b) depicts the electronics system, consisting of a front-end data acquisition module (6U chassis, 128-channel differential inputs) and a back-end control system. The LabVIEW-based software enables real-time monitoring and data decoding, with a low noise level (0.6 mV) and dynamic range of 3000:1, supporting 50 MS/s sampling with 14 bits

Credit

Jia-Jun Zhang

Usage Restrictions

Credit must be given to the creator. Only noncommercial uses of the work are permitted.

License

CC BY-NC
